960X960mm P5 P6.67 P8 P10 outdoor Football Soccer Sports Perimeter Video screen stadium led display

Name: 960X960mm P5 P667 P8 P10 outdoor Football Soccer Sports Perimeter Video screen stadium led display
Brand: JuCaiYuan
Price: 1 USD

Quality 960X960mm P5 P6.67 P8 P10 outdoor Football Soccer Sports Perimeter Video screen stadium led display for sale

Brand Name : JuCaiYuan

Model Number : P8

Certification : CE/ROHS/FCC

Place of Origin : Shenzhen,China

MOQ : 1 Square meter

Price : negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000sqm per month

Delivery Time : 3-25 working days after finished the payment

Packaging Details : Strong Carton Box, Standard Wood Case, Flight Case etc

product : Transparent P2.5 mm LED Display

Brightness : Over 5000nits

Warranty : 2 Years

Application : Indoor

Technology : Frontage-lighting

Screen Dimension : Customized

Material : Acrylic Frame Rental Led Wall

High Light : transparent led curtain display, glass wall led display

Contact Now

Overview

Quick Details

Application:: stadium led display

Color:: RGB

Panel Size:: 640*640mm

Pixel Pitch:: 160000 dots/sqm

Place of Origin:: Guangdong, China

Model Number:: P2.976

Brand Name:: JUCAIYUAN

Pixels:: 2.976mm

Brightness of White:: 1000cd/sqm

Port Type:: SMD2121

Package Mode:: HUB75

Warranty:: 1 Years

Pixel resolution:: 128*64mm

scan mode:: 1/32 Scan

Gray scale:: 16 bits

Refresh frequency:: 1920Hz

Lifetime:: 100,000hrs

Supply Ability

Supply Ability: 10000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: quality carton with full wood box packing

Port: Shenzhen,Hongkong

Picture Example:

Lead Time:

Quantity(Pieces)	1 - 100	101 - 300	>300
Est. Time(days)	15	30	To be negotiated

960X960mm P5 P6.67 P8 P10 outdoor Football Soccer Sports Perimeter

Video screen stadium led display

Product Description

Module Specification
Pitch	4mm	10mm
Size	320mm(H)x160mm(W)	320mm(H)x160mm(W)
Module Resolution	80(H)x40(V)	32(H)x16(V)
Density	62500pixels/m2	10000pixels/m2
LED Lamps	SMD1919	SMD3525
Driver IC	Customizable	Customizable
Driver Mode	1/10 Scan	1/2 Scan
Modules Refresh	1920hz-3840hz	960hz-3840hz
Electricity Parameter
Brightness	5500-6500cd/m2	6000-7500cd/m2
View Angle	140 degree ( horizontal) 140degree(vertical)	140 degree ( horizontal) 140degree(vertical)
View Distance	4m-250m	10m-250m
Gray Scale	65536	65536
Display Color	3-in-1 RGB	3-in-1 RGB
Power Supply
Operation Power	AC100-240V 50-60HZ Switch-able	AC100-240V 50-60HZ Switch-able
Maxim Power Consumption	1600 w/m2	1600 w/m2
Average Power Consumption	800 w/m2	800 w/m2
Reliability
Temperature Storage	-10~60 ℃	-10~60 ℃
Humidity Storage	10~90%	10~90%
Operating Life	>100,000 hours	>100,000 hours
MTBF	>10,000 hours	>10,000 hours
Continuous Working Time	>48 hours	>48 hours
Protection Level	IP65	IP65
Out of Control Pixel Rate	<0.03%	<0.03%

LED MODULE AGING DEPARTMENT

PACKAGING DEPARTMENT
